Aiko Battery Pallet Truck 2 T Wide Semi-Electric Red | Model : PT-BCD20J-B

Save $88.16
AikoSKU: PT-BCD20J-B

Price:
Sale price$972.84 Regular price$1,061.00

Tax included Shipping calculated at checkout

Description

Specifications :

  • Model : Aiko-BCD20JB
  • Characteristics
    • Type of operation : Pedestrian
    • Rated Capacity :  2000 kg
    • Lift height : 200 mm
    • Service weight with battery : 155 kg
    • Load Center : 600 mm
    • Axle center to fork face : 944 mm
    • Wheel base : 1243 mm
    • Controller : Curtis
  • Wheels
    • Wheels type : Polyurethane
    • Driving wheels size : Φ210 x 70
    • Loading wheels size : Φ80 x 60
    • Wheels, number front/rear (x= driven) : 1x/4
    • Track width, rear and loading side : 400/535 mm
    • Wheel types : Nylon (for hard floors) or PU (for smooth and clean floors)
  • Dimensions
    • Overall Length : 1620 mm
    • Length to fork face : 470 mm
    • Overall width : 550/685 mm
    • Fork Dimensions : 50/150/1150 mm
    • Width of forks : 550/685 mm
    • Lowered height : 85 mm
    • Min. Ground clearance : 35 mm
    • Height draw bar in driving position min/max : 720/1090 mm
    • Aisle width with pallet 1000 x 1200 across forks : 1825 mm
    • Aisle width with pallet 800 x 1200 along forks : 1875 mm
    • Min. turning radius : 1415 mm
  • Performance
    • Travel speed, with/without load : 4.2/4.5 km/h
    • Max. Grade ability laden/unladen : 3/10 %
    • Service brake type : Electromagnetic brake
  • Drive and Battery
    • Drive motor, output s2 60 min : 0.75 kW
    • Battery voltage/rated capacity : 24/32 V/Ah
    • Battery Weight (± 5%) : 20.2 kg
    • Charger Spec : 24V/5A
  • Other
    • Type of drive control : DC
    • Sound pressure level at driver's ear : < 70
    • Steering type : Mechanical Steering
